1. Warranty: 2 Years
2. Energy Efficiency Level DOE VI
3. All units are 100% burn in and tested
4. Short circuit and overload protection
5. Over voltage and over current protection
6. Class II Construction
7. OEM & ODM Service available
|Input:||Universal 100-240VAC 50/60Hz 0.6A|
|DC plug :||5.5*2.1*10mm/5.5*2.5*10mm(2.5x0.7mm*10mm / 3.5x1.35mm *10mm/ 4.0x1.7mm*10mm / micro USB / USB / Type C (OEM/ODM)|
|DC plug type:||straight type/90° type|
|DC Wire :||UL2464/2468 16/18/20/22/24AWG Cable / SPT-01 / L=1M/1.2M/1.5M/1.8M/2M(OEM/ODM)|
|AC plug :||EU US UK AU EK AR plug or interchangeable plug available )|
|Hold-up Time:||10mS@Full Load|
|Operating Temp:||0ºC to +40ºC|
|Storage Temp :||-20ºC to +80ºC|
|Relative Humidity:||Operating:20 to 80% RH / Storage:10 to 90% RH|
|Cooling:||Natural Convection Cooling|
Our products have passed most of safety approvals in the world including UL, cUL, FCC,GS, CE,GS, BS,SAA,C-tick, RCM, KC,PSE,S-mark, BSMI, CCC , CB, etc.
US Market: UL cUL FCC, DoE Level VI Efficiency, CEC
EU Market: CB CE GS RoHS, ErP
UK Market: CB CE BS, ErP
AU Market: SAA C-tick
AR Market: S-Mark
EK Market: KC KCC
JP Market: PSE
Taiwan Market: BSMI
|UL/cUL||UL 60950 (UL No.: E361658)|
|FCC||47 CFR FCC Part 15 Subpart B:2013|
|PSE:||J60950 / J55022/J55023/J55024|
|IRAM||IEC60950 / IRAM 2063:2009|
* CCTV, HDDBOX, DVR,LED-TV, Set Top Box, POS, IP Camera
* Mini sound box, Keyboard, DVR
* Robot vacuum cleaner, etc
* LED strip, LED light, LED table lamp.
* Router, amplifier, CCTV camera, hair clipper, recliner
* Home appliances, setup box, speaker
* Audio & Video equipment
* Wireless communication electronics
Why choose Merryking?
12 Years rich experience:
Working with famous company from USA.
Less than 0.2% RGD Guarantee:
Professional QC team to guarantee high quality products.
on-production ---- ( QC )
final inspection before delivery ---- ( QA )
Meet AQL Standards
Short Lead time:
Urgent : 15 days
Conventional : 22 days
As a leading manufacturer of AC DC adapter and USB charger in Shenzhen, China, MERRYKING has been specialized in power supply products for over 14 years.
Focusing on AC adapter marketing and manufacturing, MERRYKING has scientific, intact and efficient quality management system, which extends from product designing, raw material control, on-spot production management to after-sale services with constant, stable and reliable quality assurance.
ISO9001:2008 system is fully implemented in our management. Our products have passed most of safety approvals in the world, including UL, cUL, FCC, PSE, GS, CE, SAA, CCC, C-tick, CB, etc.
Welcome to visit our company website merryking.en.made-in-china.com for further information!
Merryking Quality Assurance:
Hi-pot testing at 3000V.
Board Level Burn-in 60 degrees in controlled oven Perform Functional Testing.
ATE test in the automatic test system for all the Merryking adapters.
Production Capacity: 500,000 PCS/MONTH
SMT: 3 Sets
Board Mounting Production Line: 4 Lines
Product Assembly Line: 8 Lines
Aging Test Stand: 9 Sets (24-hour working)
1. AC DC power supply adapter for Lenovo, Asus, Toshiba, Benq, HP, Notebook, LED lightings, CCTV, etc.
2. Smart device surge protection for over voltage, short circuit protection.
3. 4-protection AC adapter: temperature, short circuit, over voltage, over current.
4. Strong performance designed for heavy duty and long-time usage.
5. Different AC plug for US, EU, UK (BS) and AU to meet your unique requirements.
6. Portable and interchangeable, especially convenient for your business trips and travellings.
7. Centered adapter service: AC DC power adapter; desktop power supply adapter; switching power supply adapter; waterproof LED power supply adapter; linear power supply adapter; USB chargers adapter, In-car charger adapter, etc.
8. Professional OEM/ODM service and product solutions to meet your requirements.
9. FREE SAMPLE for your test before formal order.
10. Quick response and short delivery time.
1. Samples will be sent via DHL, UPS, FedEx, TNT, EMS, etc., generally it takes 2-5 working days to arrive in most countries.
2. Bulk goods will be sent by sea or air.
3. We offer EXW, FOB, CIF, C&F, etc.
Q: What is your MOQ?
Q: How about your warranty for your products?
A :we offer 2-year warranty for our products.
Q: How can I finish my payment?
A: T/T, L/C, Western Union are all acceptable, PayPal is also OK.
Q: What is shipping method?
A: Samples will be sent via DHL, UPS, FedEX, TNT, EMS, etc.
Bulk goods will be sent by sea or air.
Q: How about sample? For free?
A: YES! Generally we offer 1-3PCS sample(s) for your test FOR FREE, but you need to bear the freight cost. If your sample quantity is more than 3PCS, we will charge some sample fee, and we might return it when you place your first formal order as we discuss ahead.
