Basic Info.
Model NO.
S-35-5
Output Type
Warranty
Output Power
1 - 50W
Input Voltage
Connection Mode
Series Switching Power Supply
Starting Mode
Self-excited Switching Power Supply
Voltage Regulating Mode
Frequency Modulation Type
Power Supplying System
Terminal Power Distribution Equipment
Energy Transmission
Modulation System
Certification
CE, RoHS, ISO, CCC, CB, FCC
Brand
Mwish
Package Info
45PCS/CTN
Weight;
0.4kgs
Trademark
MWISH
Transport Package
Export Package
Specification
129*98*38 mm
Origin
China
HS Code
8504401990
Product Description
| *Low price and high reliablity *105ºC Ootput capacitor *AC input power suitable for the world *High efficiency and low operation tenperature *Sofft-start current can reduce the AC input impact effecticly *With short-circuit and overload protection *Compact size,light weight *100%full-load bum-in test *Installed with EMI filter, mlnlmum wave | ||||
| Specification ModelNo. | S-35-5 | S-35-12 | S-35-15 | S-35-24 |
| DC output voltage | 5V | 12V | 24V | 48V |
| Output voltage range (Note:2) | ±2% | ±1% | ±1% | ±1% |
| Rated output current | 7A | 3A | 2.4A | 1.5A |
| output current range | 0~7A | 0~3A | 0~2.4A | 0~1.5A |
| Wave and noise (Note:3) | 100mVp-p | 75mVp-p | 75mVp-p | 50mVp-p |
| Inlet stability (Note:4) | ±0.5% | ±0.5% | ±0.5% | ±0.5% |
| Load stability (Note:5) | ±1% | ±0.5% | ±0.5% | ±0.5% |
| DC output power | 35W | 35W | 35W | 35W |
| Efficiency | 80% | 83% | 84% | 85% |
| Adjustable range for DC voltage | ±10% | ±10% | ±10% | ±10% |
| AC input voltage range | 85-132VAC/170-264VAC 47-63Hz | |||
| output current | 0.8A/115V 0.45A/230V | |||
| AC rush current | 18A/115V 36A/230V | |||
| Leakage current | <0.5mA/240VAC | |||
| Overload protection | 105%-150% hiccup mode,auto-recovery | |||
| Over-Voltage protection | 115%-135% rated output voltage | |||
| High-temperature protection | -10ºC~+60ºC,20%~90%RH | |||
| Temperaut re cofficient | 0.03%/ºC(0~50ºC) | |||
| Setup,rise,hold up time | 200ms,100ms,30ms | |||
| Vibration | 10~500Hz, 2G 10min,1 cycle Pariod for 60min, Each axes | |||
| Withstand voltage | I/P-O/P:1.5Kv I/P-FG:1.5KV O/P-FG:0.5KV 1minute | |||
| Insulation resistance | I/P-O/P IP/FG OP-FG:500VDC/100MΩ | |||
| Working temperature and humidity | -10ºC~+60ºC,20%~90%RH | |||
| Overall dimension | 129*98*38 mm | |||
| Safety Standards | Meet UL 1012 requirement | |||
| EMC Standards | Meet FCC PART15J Conduction class B | |||
| Weight | 0.4Kgs | |||
| Note: 1.The testina condition for The Paramenter is:230VAC input,rated load, 25ºC 70% RH Temperature 2.Error incude the seting error, line stability and load stability 3.Wave test:adopt in "A12"double wire for 20MHz,and 0.1 UF capacitor short-circuit for interrupt bug 4.Inlet voItage stability test:When is over load,the lowest voItage of inlet is up to the hiqhest voltaqe 5.Load stability test:the load is from 0% to 100% 6.C3,4 must be knocked down | ||||
