Feature:
· High Efficiency,Efficiency is 92% when input voltage is 230v, Efficiency is 90% when input voltage is 110v
· CE FCC RoHS Certificate and DOE Level VI Standard
· With LED indicator light display
· With PC material , it's high temperature resistance and flame retardant
· With 4 protections : Short Circuit Protection ; Over Voltage Protection ;Over
Current Protection ; Over temperature protection
· Real power,full load aging testing,100% loading testing.
Power consumption<0.3W
· MTBF > 50,000 hours
Part. No. | PC-240250 |
Product size | 215*125*65mm |
AC Input | 100~240V AC 50/60Hz Max:90~264V AC 47/63Hz |
DC Voltage | 24V |
Rate Current | 25A |
Rate Power | 600W |
Material | 100% PC |
Certification | Approved CE ROHS FCC C-TICK certification |
Voltage Tolerance | ±5% |
Line Regulation | ±1% |
Load Regulation | ±5% |
Efficiency | >89% |
Short Circuit Protection | Shall be protected when any output operation in circuit short condition, and shall be auto restart when the fault condition is removed. |
Over Current Protection | 130%~150% |
Over Voltage Protection | 115%~135% |
Operating Temperature | -10ºC~50ºC(±10ºC) |
Relative Humidity | 20%~90% RH |
Storage Temperature | -40ºC~80ºC(±10ºC) |
DC Connector | 4PIN or 6PIN(Customized available) |
DC Cable | 0.9M,1.2M, 1.5M(Customized available) |
AC Cable | USA/UK/EU/AU/India Plugs(Customized available) |
